Description
Views: 75
Mesh banners are made of PVC coated polyester base fabric. Its basket weave appearance allows air-flow through making it ideal for large building, stadium and fence wraps Mesh banner from Duraflex lines includes screen printer banner material in a variety of widths and unique scrim patterns that will make your banners stand out from the rest. Most are perfect for 5meter wide-format printing. Ranging from 6.5 to 11.8 ounces in weight, these materials also work with UV, solvent, eco-solvent and Latex printers. All of the products in this line can also be used in building wrap applications. Several can also be used for fence graphics, display systems and barrier graphics.
Our mesh screen printer banner material is one of the many REACH compliant materials from Duletai New Material. Protecting the environment and the health of humans from risks associated with chemicals is the main goal of the REACH regulation. The regulation requires that companies “identify and manage the risks linked to the substances they manufacture and market. They have to demonstrate to ECHA how the substance can be safely used, and they must communicate the risk management measures to the users” (ECHA).
Mesh banners specifications:
Base fabric: Polyester
Material: Polyester
Technology: PVC Coating
Color: Customized
Surface: Matte, Gloss, Semi-gloss
Weight: 130-1000gsm
Width: 1.02 – 5.0 meter
Packing: Kraft paper or hard tube
Fire Resistance: B1 / NFPA701
Welding: RF (Heat Sealable)
Printing: Solvent Eco solvent UV Latex Screen printing
Additional treatment: Anti-uv, Anti-mildew, Anti-cold, Padding
| Item NO. | Weight | Basic fabric | OZ/SQ.YD | Width |
| DLT-BXN0606 | 220gsm | 1000D*1000D / 6*6 | 6.5 | 1.02m-5.0m |
| DLT-BX0909 | 170gsm | 840D*840D / 9*9 | 5.0 | 1.02m-5.0m |
| DLT-BXN0909 | 240gsm | 1000D*1000D / 9*9 | 7.1 | 1.02m-5.0m |
| DLT-BX0913 | 250gsm | 1000D*1000D / 9*13 | 7.4 | 1.02m-5.0m |
| DLT-BXN0913 | 250gsm | 1000D*1000D / 9*13 | 7.4 | 1.02m-5.0m |
| DLT-BX1812 | 250gsm | 500D*1000D / 18*12 | 7.4 | 1.02m-5.0m |
| DLT-BX1809 | 300gsm | 1000D*1000D / 18*9 | 8.9 | 1.02m-5.0m |
| DLT-BX1820 | 230gsm | 500D*500D / 18*20 | 6.8 | 1.02m-5.0m |
| DLT-BX0914 | 360gsm | 1000D*1000D / 9*14 | 10.6 | 1.02m-5.0m |
| DLT-BXN1212 | 260gsm | 1000D*1000D / 12*12 | 7.7 | 1.02m-5.0m |
| DLT-BX1212 | 320gsm | 1000D*1000D / 12*12 | 9.5 | 1.02m-5.0m |
| DLT-BXD1011 DOUBLE PRINTING | 400gsm | 2520D*1500D / 10*11 | 11.8 | 1.02m-5.0m |
| DLT-BXN1212 | 270gsm | 1000D*1000D / 12*12 | 8.0 | 1.02m-5.0m |
DLT-BXN0606 (Click image to enlarge)
DLT-BX0909 (Click image to enlarge)
DLT-BXN0909 (Click image to enlarge)
DLT-BX0913 (Click image to enlarge)
DLT-BXN0913 (Click image to enlarge)
DLT-BX1812 (Click image to enlarge)
DLT-BX1809 (Click image to enlarge)
DLT-BX1820 (Click image to enlarge)
DLT-BX0914(Click image to enlarge)
DLT-BXN1212 (Click image to enlarge)
DLT-BX1212 (Click image to enlarge)
DLT-BXD1011 DOUBLE PRINTING (Click image to enlarge)
DLT-BXN1212 (Click image to enlarge)
Mesh banner applications
Print outdoor advertisement
Fence
Building protection bar
Building warps
Fence Graphics
Stadium Graphics
Barricade Graphics
Street Graphics
Indoor Out door Graphics
