Glassfiber window curtain fabric is ideal for roller blinds. Because of the different composition of in these yarns there may also be a notable resulit in how the yarn responds to cutting. Polyester yarn is sensitive to flame and will provide a “clean” cut edge on the shade when ultrasonic cut. It is usually to use candles on the cut edge of the fabric to burn off any remaining exposed fibers. Fiberglass on the other hand does not respond to flame. If the pvc coating is stripped away from the fiberglass base fabric, such as in the case of a dull knife being pulled through the fabric, small fiberglass fibers may also be visible on the shades edge. If noticeable, these fibers would need to be trimmed, typically with scissors or an electric trimmer. Neither material will continue to fray from the fabric once initially trimmed and should not present a problem for the end user.
Glassfiber window curtain fabric specifications:
| Fiberglass standard | DuraBlinds DLT-1007 | |
| Structure: | 4-Layer: PVC+PVC black fim+Fiber Glass+PVC |
| Width: | 1.02m-3.2m |
| Weight: | 560g(±10g)/sqm |
| Thickness: | 0.43mm± 0.01mm |
| Blockout rate: | Blackout (Complies to AS 2663.3.1999) |
| Color fastness: | 5-6 (Blue Scale) Tested to ISO 105-B02:2014 |
| Flame retardant: | California U.S. Title 19 (small scale), NFPA 701-2010 TM#1 (small scale), BS 5867 2008 Part 2 Type B Performance. |
| Tensile strength: | ≥2000 N/5cm DIN53354 Zonal N/5cm |
| Tear strength: | ≥80 N/5cm DIN53363 Zonal N/5cm |
| Peel off strength: | ≥80 N/5cm DIN53357 Zonal N/5cm |
| Suitable temperature: | -20° to +70° |
| Package: | Inner packing: hardboard tube and kraft paper/ poly bag Outer packing: hardboard tube and tube cover |
| Meter per roll: | 30m |
Light & Solar Optical Properties
| Colours | SolarTransmittance | Solar Reflectance | Solar Absorbance | Visible Light Transmittance | UV Transmittance | Openness Factor |
| White | 0% | 71% | 29% | 0% | 0% | 0% |
| Ivory | 0% | 71% | 29% | 0% | 0% | 0% |
| Grey | 0% | 70% | 28% | 0% | 0% | 0% |
| Black | 0% | 4% | 96% | 0% | 0% | 0% |
| Shading Coefficient | G-Value | |||||
| Colours | 3mm CI. | 6mm CI. | 6mm H.A. | 3mm CI. | 6mm CI. | 6mm H.A. |
| White | 0.28 | 0.26 | 0.28 | 0.24 | 0.26 | 0.26 |
| Ivory | 0.28 | 0.26 | 0.28 | 0.24 | 0.24 | 0.25 |
| Grey | 0.24 | 0.25 | 0.25 | 0.25 | 0.26 | 0.26 |
| Black | 0.72 | 0.72 | 0.66 | 0.62 | 0.62 | 0.57 |
 |
 |
 |
 |
Glassfiber window curtain fabric features:
Glassfiber window curtain fabric versions:
We have developed 2 types of window curtain fabrics with fiberglass core. DLT-1100 series Low desity base fabric(Lite) and DLT-1000 series High desity base fabric (Standard). These 2 versions all have the same function and life time, difference is the lite version DLT-1100 surface is fiber textured and standard version DLT-1000 surface is smooth. And the weight is different according to the follow spec of the 2 version.
