Fiberglass curtain fabric is a new developing high-grade fabrics, using the most advanced high-quality glass substrate, the special treatment of environmental PVC, and RoHS environmental standards, the recommended ambient temperature can still maintain good ductility and recoverability. 100% shielding provides complete privacy for the construction and the best thermal insulation effect, creating a comfortable office and home environment. The products are environment protection , flame retardant, antibacterial and anti-fungal, widely used in high-end hotels, office buildings, offices, hospitals and so on.
| Fiberglass standard | DuraBlinds DLT-1003 | |
| Structure: | 4-Layer: PVC+PVC black fim+Fiber Glass+PVC |
| Width: | 1.02m-3.2m |
| Weight: | 560g(±10g)/sqm |
| Thickness: | 0.43mm± 0.01mm |
| Blockout rate: | Blackout (Complies to AS 2663.3.1999) |
| Color fastness: | 5-6 (Blue Scale) Tested to ISO 105-B02:2014 |
| Flame retardant: | California U.S. Title 19 (small scale), NFPA 701-2010 TM#1 (small scale), BS 5867 2008 Part 2 Type B Performance. |
| Tensile strength: | ≥2000 N/5cm DIN53354 Zonal N/5cm |
| Tear strength: | ≥80 N/5cm DIN53363 Zonal N/5cm |
| Peel off strength: | ≥80 N/5cm DIN53357 Zonal N/5cm |
| Suitable temperature: | -20° to +70° |
| Package: | Inner packing: hardboard tube and kraft paper/ poly bag Outer packing: hardboard tube and tube cover |
| Meter per roll: | 30m |
Light & Solar Optical Properties
| Colours | SolarTransmittance | Solar Reflectance | Solar Absorbance | Visible Light Transmittance | UV Transmittance | Openness Factor |
| White | 0% | 71% | 29% | 0% | 0% | 0% |
| Ivory | 0% | 71% | 29% | 0% | 0% | 0% |
| Grey | 0% | 70% | 28% | 0% | 0% | 0% |
| Black | 0% | 4% | 96% | 0% | 0% | 0% |
| Shading Coefficient | G-Value | |||||
| Colours | 3mm CI. | 6mm CI. | 6mm H.A. | 3mm CI. | 6mm CI. | 6mm H.A. |
| White | 0.28 | 0.26 | 0.28 | 0.24 | 0.26 | 0.26 |
| Ivory | 0.28 | 0.26 | 0.28 | 0.24 | 0.24 | 0.25 |
| Grey | 0.24 | 0.25 | 0.25 | 0.25 | 0.26 | 0.26 |
| Black | 0.72 | 0.72 | 0.66 | 0.62 | 0.62 | 0.57 |
 |
 |
 |
 |
Fiberglass curtain fabric features:
Fiberglass curtain fabric versions:
We have developed 2 types of window curtain fabrics with fiberglass core. DLT-1100 series Low desity base fabric(Lite) and DLT-1000 series High desity base fabric (Standard). These 2 versions all have the same function and life time, difference is the lite version DLT-1100 surface is fiber textured and standard version DLT-1000 surface is smooth. And the weight is different according to the follow spec of the 2 version.
