Fiberglass Lite | DuraBlinds DLT-1103

Roller Blinds Fabric

Duletai New Material > Shop > Products > Roller Blinds Fabric > Fiberglass Lite > Fiberglass Lite | DuraBlinds DLT-1103
Awaiting product image

Fiberglass Lite | DuraBlinds DLT-1103

SKU: DLT-1103 Grey Category:

Description

Views: 116

Fiberglass blockout fabric offers quality and lasting solutions for solar protection for both business and residential buildings. This range of fiberglass blockout fabric are developed using woven fiberglass yarns with a coating that ensures all products provide durable tensile strength and offer both dimensional and colour stability. Solar protection using fiberglass blockout fabric offers high protection while maintaining the natural, incoming light for optimal visual and thermal comfort. This material is widly used in home decoration, office building, airport, shopping mall and hospitals.

fiberglass blockout fabric

fiberglass window curtain fabric

Fiberglass rollber blinds fabric specifications:

Fiberglass Lite | DuraBlinds DLT-1103 Grey
Color: Grey
Structure: 4-Layer: PVC+PVC black fim+Fiber Glass+PVC
Width: 1.02m-2.5m
Weight: 420g(±10g)/sqm
Thickness: 0.34mm± 0.01mm
Blockout rate: Blackout (Complies to AS 2663.3.1999)
Color fastness: 5-6 (Blue Scale) Tested to ISO 105-B02:2014
Flame retardant: California U.S. Title 19 (small scale), NFPA 701-2010 TM#1 (small scale), BS 5867 2008 Part 2 Type B Performance.
Tensile strength: ≥2000 N/5cm DIN53354 Zonal N/5cm
Tear strength: ≥80 N/5cm DIN53363 Zonal N/5cm
Peel off strength: ≥80 N/5cm DIN53357 Zonal N/5cm
Suitable temperature: -20° to +70°
Package: Inner packing: hardboard tube and kraft paper/ poly bag
Outer packing: hardboard tube and tube cover
Meter per roll: 30m

Light & Solar Optical Properties

Colours SolarTransmittance Solar Reflectance Solar Absorbance Visible Light Transmittance UV Transmittance Openness Factor
White 0% 71% 29% 0% 0% 0%
Ivory 0% 71% 29% 0% 0% 0%
Grey 0% 70% 28% 0% 0% 0%
Black 0% 4% 96% 0% 0% 0%
  Shading Coefficient G-Value
Colours 3mm CI. 6mm CI. 6mm H.A. 3mm CI. 6mm CI. 6mm H.A.
White 0.28 0.26 0.28 0.24 0.26 0.26
Ivory 0.28 0.26 0.28 0.24 0.24 0.25
Grey 0.24 0.25 0.25 0.25 0.26 0.26
Black 0.72 0.72 0.66 0.62 0.62 0.57

fiberglass roller blind fabric

5year

roller blinds fabric

rohs reach nfpa701 BS5867-2

Fiberglass roller blinds fabric features:

  1. MILDEW RESISTANT
    A process of materials used in fabric manufacturing to prevent biodegradation and chemical decomposition.
  2. ANTI-UV
    Glass fiber can be a better alternative to polymers when it comes to UV degradation.
  3. ANTI-STATIC
    Reduces static electricity, which can damage electrical components such as computer or ignite flammable liquids.
  4. FLAME RETARDANT
    Fire resistant reached B1 grade. Actually according to testing result, it’s better than B1.
  5. 100% BLOCKOUT
    Sufficient to blockout 100% of a direct light source, maximum light absorption, heat insulation and low thermal conductivity.
  6. WASHABLE
    Washable, waterproof fabric to keep mud and dirt off, easy to clean.
  7. FLATNESS
    Excellent flatness comparing with polyester core fabric, no curling edges even with 3m width.

Fiberglass rollber blinds fabric with UV printing:

Fiberglass rollber blinds fabric applications:

Roller, Roman and Panel Window Blinds.

fiberglass blockout fabric

Fiberglass window shade

Fiberglass roller blinds fabric versions:

We have developed 2 types of window curtain fabrics with fiberglass core. DLT-1100 series Low desity base fabric(Lite) and DLT-1000 series High desity base fabric (Standard). These 2 versions all have the same function and life time, difference is the lite version DLT-1100 surface is fiber textured and standard version DLT-1000 surface is smooth. And the weight is different according to the follow spec of the 2 version.

Fiberglass window shade
